Kohler K-10430 - Optional Water Temperature Limiting Adjustment

8. Optional Water Temperature Limiting Adjustment
Remove the plug button, setscrew, handle, and bonnet.
Reposition the indexer to stop the valve stem at the desired
maximum temperature.
Turn the handle to the full hot position and check the water
temperature.
Repeat the above procedures until the desired temperature is
reached.
Reinstall the plug button.
Bonnet
Handle
Indexer
Splines
Valve Stem
Setscrew
Plug
Button
Kohler Co. 9 1036178-2-F
