Kohler K-168 Installation Guide

1. Install the Escutcheon (Optional)
For 1-hole Installations
Use the appropriate washer (provided).
For 3-hole Installations
NOTE: When installing in marble countertops, use the gaskets
provided. Remove the adhesive backing and apply the gaskets over
the unused sink holes with the adhesive side down.
Apply a bead of plumbers putty or other sealant to the underside
of the escutcheon according to the manufacturer’s instructions.
Insert the O-ring into the groove of the spacer.
Set the spacer with gasket under the center hole of the escutcheon
with the gasket in position to make contact with the countertop.
Align the center hole of the escutcheon with the center hole of the
sink.
Apply
plumbers
putty.
Spacer with
Gasket
Center Hole
Center Hole
Sink
Optional Escutcheon
Spacer
O-Ring
Kohler Co. 3 1015073-2-D
