1. Install the Soap Dispenser
Remove the nut from the escutcheon.
Apply plumbers putty in the groove on the underside of the
escutcheon according to the putty manufacturer’s instructions.
Position the escutcheon in the desired mounting hole.
From underneath the sink, thread the nut onto the escutcheon.
Tighten the nut until the escutcheon is firmly held in place.
Press the body firmly onto the pump assembly and escutcheon.
Fill the bottle with soap.
Insert the soap tube onto the pump assembly.
Insert the soap tube and pump assembly onto the escutcheon.
Escutcheon
Bottle
Nut
Cap
Apply Plumbers
Putty Here.
Pump
Assembly
Kohler Co. 3 1037318-2-C
