K-2973 - 1/2″ Valve Roughing-In
Min
Finished Wall
Max
Finished Wall
2-7/16"
(62 mm)
3-3/4" (95 mm)
3-1/2" (89 mm)
1/2"
(13 mm)
4-5/8" (117 mm)
4-5/8" (117 mm)
1-3/16" (30 mm)
6-3/8"
(162 mm)
3-1/8"
(79 mm)
1-7/16"
(37 mm)
1/2" NPT
Cold Inlet
1/2" NPT
Hot Inlet
1/2" NPT
Shower Outlet
Stop
1-3/16" (30 mm)
2-5/16"
(59 mm)
2-1/16"
(52 mm)
Kohler Co. 7 1205551-2-C
