K-2976 - 3/4″ Valve Roughing-In
1-3/16" (30 mm)
4-5/8" (117 mm)
1/2"
(13 mm)
3-1/2" (89 mm)
3-3/4" (95 mm)
2-7/16" (62 mm)
Min
Finished Wall
Max
Finished Wall
2-3/8"
(60 mm)
1-3/4"
(44 mm)
Stop
3/4" NPT
Shower Outlet
3/4" NPT
Hot Inlet
3/4" NPT
Cold Inlet
3/4" NPT
Bath Outlet
1-7/16"
(37 mm)
3-3/16"
(81 mm)
6-15/16"
(176 mm)
2-1/16"
(52 mm)
4-13/16" (122 mm)
Kohler Co. 9 1205551-2-C
