Kohler K-3492 Installation And Care Guide

Kohler Co. 9 1035530-X2-A
9. Install the Collar
 Place the wiring harness plug, level switch wire, and refill tube on the floor so they extend out the rear access
opening.
 Tape them to the floor so they will not be pinched or damaged.
 Install the collar onto the tank.
 Clip the spray shield into place over the fill valve.
Tape
Level
Switch
Wire
Electrical
Plug
Centerline
Refill Tube
Wiring Harness Plug
Spray Shield
Collar
Ta n k
