2. Install the Shower Hose
NOTE: Only one gasket is required for installations without the
handle.
Place the gasket into the end of the hose with the wrench flats.
Thread the end of the hose with the wrench flats into the shower
outlet.
Wrench tighten.
Insert the screen washer into the other end of the hose.
Depending on the installation type, thread the hose into either the
handshower or the handle extension.
Gasket
Wrench-Flats
Screen
Washer
1000524-2-AD 4 Kohler Co.
