-6-
B. Roughing-In
DANGER: Risk of electric shock.
NOTE:
WARNING: Risk of electric shock.
Disconnect power
before servicing.
This product is designed to work with wall mounted
electrical and water supplies. It is shown in the roughing-in.
Connect only to
circuits protected by Ground-Fault Circuit-Interrupters
(GFCI s) or Earth-Leakage Circuit-Breakers (ELCB s).
Keep bath and shower away from electrical parts
(such as remote controller, receptacle, audio input
apparatus and so on).
When the electrical supply is mounted on the wall, a GFCI or
ELCB protected and water proof receptacle is required.
Follow the dimensional information exactly when installing a
hardwire electrical supply.
''
B.
(GFCI) (ELCB)
(
)
(GFCI)
(ELCB)
Fig.#7
7
Fig.#8
8
Remove old gasket from the floor and
closet flange with a putty knife.
Remove old T-bolts and discard them.
if a new toilet is not installed
immediately, temporarily stuff a rag in
the closet flange.
NOTICE:
T
Closet Flange
A. To Remove Existing Toilet
Turn off the water supply. Flush the toilet, and use a sponge
to remove the remaining water from the tank and bowl.
Disconnect the supply shut-off valve (if present), and remove
the old tank and bowl.
A.
()
INSTALLATION
150mm
305mm
70mm
70mm
Supply Stop (with filter)
()
GFCI-Protected 16A Receptacle(water proof)
16
The wall location of the electrical and
water supply are interchangeable.
Floor Flange
T-Bolts
T
1144585-T01-A
