Kohler K-4709 Specification

Technical Information
Fixture:
Configuration 20 psi (1.38 bar) - 80 psi
(5.52 bar)
Electrical rating 120 VAC / 60 Hz / 1260 W
Power cord length 46″ (1.17 m)
A dedicated circuit protected with a Class A Ground-Fault
Circuit-Interrupter (GFCI) or Residual Current Device
(RCD) is required.
Installation Notes
Install this product according to the installation guide.
14-9/16"
(370 mm)
4-7/8"
(124 mm)
2"
(51 mm)
7/8" (22 mm)
11-1/16"
(281 mm)
16-3/8" (416 mm)
16-3/8" (416 mm)
20-1/4" (514 mm)
7-13/16"
(198 mm)
2" (51 mm)
6"
(152 mm)
Min
ELECTRICAL SERVICE DETAIL
REMOTE
32" (813 mm) R.
The receptacle should be located at least 6" (152 mm)
above the floor line, and within a 32" (813 mm) radius
measured 2" (51 mm) to the right of the toilet ledge, as
shown.
2"
(51 mm)
Product Diagram
C
3
TM - 200
C
3
TM - 200 TOILET SEAT WITH BIDET FUNCTIONALITY
P
age2of2
1054180-4-
B

Kohler K-4709 Specifications

General

Brand	Kohler
Model	K-4709
Category	Bathroom Fixtures
Language	English
