Kohler K-527 Installation Guide

2. Install the Mounting Bracket
Refer to the ″Roughing-In″ section for recommended mounting
bracket location.
Hold the bracket at the installation location. Mark the center hole
and two mounting holes on the wall.
Using a hole saw, cut a 1-3/8″ (35 mm) hole at the marked
location.
Using a 1/4″ drill bit, drill holes at the two mounting-hole
locations. Install the anchors.
Generously apply 100% silicone sealant in the groove on the back
of the mounting bracket.
Pull the cable through the center hole of the bracket.
Position the bracket with the tabs up. Secure to the wall with the
screws.
Cover the screws with 100% silicone sealant.
Anchor
1-3/8"
(35 mm)
Hole
Tabs
Apply 100%
silicone sealant.
Apply 100%
silicone
sealant.
Kohler Co. 5 1143086-2-G
