Kohler K-5401 - Remote Control Features; Front Remote Control Functions

3. Prepare the Toilet
Install a stud in each of the holes and tighten the stud until 1-1/2″ (38 mm) of the stud extends
above the finished floor.
Remove the access covers.
Remove the cap from the water inlet on the back of the toilet.
Cap
Access Cover
1-1/2"
(38 mm)
1226974-2-B 6 Kohler Co.
