Roughing-In
A =
A
Ensure clearance for faucet installation.
of Doors
Top of Cabinet to Top
1-5/8"
(41 mm)
Front of Cabinet
1-5/8"
(41 mm)
Apron
18-1/8"
(460 mm)
IMPORTANT! Before installing
this sink, verify measurement
(A) is greater than the
apron height.
8-13/16" (224 mm) = Apron
Height
Kohler Co. 3 1224364-2-B
