Kohler K-5415 User Manual

1. Preparation
IMPORTANT! Before installing this sink, verify that the distance
from the top of the cabinet to the top of the doors is greater than the
apron height.
TIP: Apply painter’s tape to the cabinet to mark cuts and protect
cabinet surfaces when cutting.
Measure and mark the hole locations.
Drill one inch holes at each marked location.
Mark vertical lines from the hole to the top of the cabinet as
shown.
Cut along the marked lines to form two slots.
Notch the cabinet to accommodate the thickness of the sink rim.
Top of sink should be flush with the top of the cabinet when
installed.
7"
(178 mm)
2-1/8"
(54 mm)
Thickness
Sink Rim
1224364-2-B 4 Kohler Co.
