Kohler Co.151274372-A05-C May 2018
B) Nozzle Clean
User shall use a soft-bristled brush to clean rear wash/front wash spray wand.
Press and hold WAND MOVE button for 2 seconds when not sitting on toilet to extend the wand.
Alternatively, press and hold FRONT WASH or REAR WASH button on side panel when not sitting
on toilet to extend the wand for cleaning or inspection.
Clean the spray wand without removing the tip:
Just use a wet soft-bristled brush to clean.
Clean the spray wand by removing the tip:
Remove nozzle tip from wand along the arrow direction as shown.
Immerse nozzle tip into cleaning solution for 2 hours
Manually clean it with a
soft-bristled brush.
Mount nozzle tip back to original position along the dismantle direction
Check nozzle clean function when power is ON
