3. Option A: Install Using Gasket/Connector
Ensure that the drain pipe extends 1-1/4″ (3.2 cm) into the drain
body. Center the shower fixture over the drain pipe.
Lubricate the gasket/connector with soap solution.
With the drain pipe inserted into the drain body, pull the
gasket/connector over the drain pipe so the raised letters face
upward.
Push the gasket/connector downward into the strainer body so it
fits tightly.
Use a hammer and caulking tool (a short, narrow piece of wood
will suffice if a caulking tool is not available) to carefully drive
the gasket/connector as far into the drain body as possible. The
drain pipe should be even with the top of the gasket/connector.
Proceed to the ″Complete the Installation″ section.
Strainer
Body
Strainer
Plate
Gasket/
Connector
Kohler Co. 7 1032220-2-B
