Kohler KARING 2.0 K-77780T-0 User Manual

Fig.#1
TOOLS AND MATERIALS REQUIRED (Not supplied)
Adjustable Wrench 2
Tape measure
Masking tape
Knife
Supply stop(with filter)
Assorted screwdrivers
Plastic anchor
Screw
T-Bolts
Flange
Expansion Bolt Kits
NOTE:
Plastic Anchor: Recommend use outside dia 10mm.
Screw: Recommend using M6 screw to match the plastic anchor.
Reference Value Unit: mm
ROUGHING-IN
Finis
hed Wall
of Outlet Finished Floor
Bottom View
Kohler reserves the right to change marked dimensions without prior notice.
Front
of Bowl
Kohler Co. 39 1250881-T01-A
