METHOD FOR CHECKING AND CLEANING FAN
WARNING
• When performing cleaning, there is a danger that dirt may scatter and cause personal injury. Wear
the protective equipment such as the protective eyeglasses and dust mask.
• When performing cleaning, always stop the engine and check that the fan is not rotating. If you
touch the fan when it is rotating, it will cause serious personal injury or death.
When the compressed air cannot be used, perform the cleaning according to the following procedure.
1.
Remove the bolts (1) (6 pieces) on the lower part of the ra-
diator grille.
2.
Pull the radiator grille backward and raise it upward.
Open the radiator grille to the fully opened position, check
that it is locked, and then release your hand.
3.
Remove the bolts (3) (4 pieces) and remove the net (4).
4.
Wipe off the soil and sand, snow, ice and such which are
stuck to the fan (5).
MAINTENANCE MAINTENANCE PROCEDURE
4-55
