PC200/220(LC)-7 00-9
FOREWORD HOW TO READ THE SHOP MANUAL
(14)
3. Filing method
• See the page number on the bottom of the page. File the pages in correct order.
• Following examples show how to read the page number.
• Revised edition mark
When a manual is revised, an edition mark ((1) (2) (3)....) is recorded on the bottom of the pages.
• Revisions
Revised pages are shown in the LIST OF REVISED PAGES next to the CONTENTS page.
4. Symbols
Important safety and quality portions are marked with the following symbols so that the shop manual will be
used practically.
5. Units
In this shop manual, the units are indicated with International System of units (SI). For reference, conven-
tionally used Gravitational System of units is indicated in parentheses { }.
Example 1 (Chassis volume):
10 - 3
Item number (10. Structure and Function, Maintenance Standard)
Consecutive page number for each item.
Example 2 (Engine volume):
12 - 5
Unit number (1. Engine)
Item number (2. Testing and Adjusting)
Consecutive page number for each item.
• Additional pages: Additional pages are indicated by a hyphen (-) and number after the page number.
File as in the example.
Example:
10-4
10-4-1
10-4-2
10-5
12-203
12-203-1
12-203-2
12-204
Added pages
Symbol Item Remarks
k
Safety Special safety precautions are necessary when performing work.
a Caution
Special technical precautions or other precautions for preserving stan-
dards are necessary when performing work.
4
Weight
Weight of parts of component or parts. Caution necessary when
selecting hoisting wire, or when working posture is important, etc.
3
Tightening
torque
Places that require special attention for tightening torque during
assembly.
2
Coat Places to be coated with adhesives, etc. during assembly.
5
Oil, coolant Places where oil, etc. must be added, and capacity.
6
Drain Places where oil, etc. must be drained, and quantity to be drained.
To Next Page
