Komatsu PC200 - Machine Dimensions (PC200-7, PC200 LC-7); Working Ranges (PC200-7, PC200 LC-7)

GENERAL SPECIFICATION DIMENSION DRAWINGS
PC200/220(LC)-7 01-3
(11)
12
DIMENSIONS
WORKING RANGES
Item Unit PC200-7 PC200LC-7
A Overall length mm 9,425 9,425
B Overall height mm 3,000 3,000
C Overall width mm 2,800 3,080
D Track shoe width mm 600 700
E Height of cab mm 3,000 3,000
F Tail swing radius mm 2,750 2,750
G Track overall length mm 4,080 4,450
H Length of track on ground mm 3,270 3,640
Min. ground clearance mm 440 440
Item Unit PC200-7 PC200LC-7
A Max. digging reach mm 9,875 9,875
B Max. digging depth mm 6,620 6,620
C Max. digging height mm 10,000 10,000
D Max. vertical wall depth mm 5,980 5,980
E Max. dumping height mm 7,110 7,110
F Min. dumping height mm 2,645 2,645
G Max. reach at ground level mm 9,700 9,700
