Komatsu PC200 - Machine Dimensions (PC220-7, PC220 LC-7); Working Ranges (PC220-7, PC220 LC-7)

GENERAL SPECIFICATION DIMENSION DRAWINGS
PC200/220(LC)-7 01-5
(11)
12
DIMENSIONS
WORKING RANGES
Item Unit PC220-7 PC220LC-7
A Overall length mm 9,885 9,885
B Overall height mm 3,160 3,160
C Overall width mm 2,980 3,280
D Track shoe width mm 600 700
E Height of cab mm 3,015 3,015
F Tail swing radius mm 2,940 2,940
G Track overall length mm 4,250 4,640
H Length of track on ground mm 3,460 3,845
Min. ground clearance mm 440 440
Item Unit PC220-7 PC220LC-7
A Max. digging reach mm 10,180 10,180
B Max. digging depth mm 6,920 6,920
C Max. digging height mm 10,000 10,000
D Max. vertical wall depth mm 6,010 6,010
E Max. dumping height mm 7,035 7,035
F Min. dumping height mm 2,530 2,530
G Max. reach at ground level mm 10,020 10,020
