SPECIFICATIONS
SPECIFICA
TIONS: W
A320-8
Item Unit W
A320-8
Operating weight
(with bolt on cutting edge (BOC))
kg 15300
Normal load kg 4480
Bucket capacity
Heaped
m
3
2.8
Engine model - KOMA
TSU SAA6D107E-3
Rated horsepower
SAE J1995 (gross)
kW {HP} /
min
-1
{rpm}
127 {170} / 2100 {2100}
ISO 14396 127 {170} / 2100 {2100}
ISO9249 / SAE
J1349 (net)
123 {165} / 2100 {2100}
A Overall length mm 7755
B Overall height (work equipment) mm 3200
C Overall height with bucket lifted up mm 5375
D Overall width mm 2590
E Min. ground clearance mm 425
F Bucket width mm 2740
G
Dumpling clearance
(*1)
Cutting edge [BOC
tip]
mm 2970 [2880]
H Dumpling reach (*1)
Cutting edge [BOC
tip]
mm 960 [1000]
I Bucket dump angle(max. height) ° 47
Min. turning radius
Cutting edge [BOC
tip]
mm 6275 [6310]
Center of outside
tire
mm 5380
Permissible towing load kN { kg} 113 {11475}
Max. speed
Forward
1st km/h 1.0 to 13.0
2nd km/h 13.0
3rd km/h 18.7
4th km/h 38.0
Reverse
1st km/h 1.0 to 13.0
2nd km/h 13.0
3rd km/h 18.7
4th km/h 38.0
SPECIFICATIONS SPECIFICATIONS
5-2
