NOTICE
Do not clean
and reuse the inner element. When replacing the outer element, replace the inner element
with new one at the same time.
When cleaning the element, do not tap it or hit it against something.
Do not use the element with damaged pleats or a damaged gasket or seal.
Wrap an unused element and keep it in a dry place.
5.
Blow dry compressed air (Max. 0.2 MPa {2.1 kg/cm
2
}
)
from the inside of the outer element along the pleats.
6.
Blow along the pleats from the outside, then blow again
from the inside.
7.
Peel off a seal after cleaning the element each time.
8.
After cleaning, illuminate the inside of the element with an
electric bulb to check.
If the element has a small hole or thin part, replace it.
CAUTION
When installing the cover (2), check O-ring (7) for scratches or damages and replace O-ring with a new
one if any.
9.
Set cleaned outer element (4).
10.
Install cover (2) and fix it with clip (1).
MAINTENANCE MAINTENANCE PROCEDURE
4-17
