Konami Turbo Grafx-16 User Manual

Howtouse
*CannotusetheoriginalTurboGrafx-16
Gamepad,HuCARD.
Connectthecable
ConnecttheGamepadto
Gamepadport.
①
ConnecttheHDMICableto
TurboGrafx-16miniandTVmonitor.
②
YoumayalsouseanACAdaptorthatsupports
5V/2.0AUSB(TypeA)output.
RegardingACAdapter
PleaseuseHORITurboGrafx-16mini
ACAdapter(HTG-005)
(soldseparately)
③
ConnectUSBcabletoACAdapter
PortandACAdapter(soldseparately)
④
ConnecttheACAdapter(soldseparately)toanelectricaloutlet.
ToTVmonitorHDMIPort
*NotallACadaptersareguaranteedtofunction.
Ifyouwishtousemorethanthreecontrollers,youmustuseMultitapfor
PCEnginemini/TurboGrafx-16mini/CoreGrafxminifromHORI(HTG-004).
Top:Player1port
Bottom:Player2port

Konami Turbo Grafx-16 Specifications

General

Brand	Konami
Model	Turbo Grafx-16
Category	Computer Hardware
Language	English
