USER INSTRUCTIONS / FUNCTION
A. HEIGHT
A. - Loosen clamp on the clip,
A. - Extend or retract the telescopic tube,
A. - retighten the clamp.
A. - Depending on the position of the feet and
A. - the position of the telescopic tube the tripod
A. - reaches a height between 700 and 1200 mm.
CHECK, MAINTAIN, CLEAN
- During maintenance work, check for possible hazards (jamming, bumping)
- For cleaning, it is best to use a slightly damp cloth and a non-abrasive detergent.
FAULT-FINDING (F) and REPAIR (R)
F: Stand wobbles R: check floor, adjust root circle, tighten clamping screws (see Fig. 4 and 5)
F: Height does not fit R: Adjust telescopic tube (see Fig. A)
F: Bracket does not hold R: Tighten clamping nut, check rubber discs and thread (see Fig. B)
TECHNICAL DATA / SPECIFICATIONS
Material
Tubes, brackets, struts, shell - steel, colour black
Screws, rivets - steel, galvanized
Parquet protector, tray, jaws - thermoplastic elastomer (TPE), black
U-bracket rear panel - felt
Clamps, guides, handles - PA
Load Bassoon
Dimensions Foot circle diameter: max. 800 mm, height: 700mm - 1200 mm
Pack size, weight 175 x 135 x 645 mm; 2.9 kg
cardboard, weight 195 x 140 x 660 mm; 3.3 kg
B. BRACKET
B. - INCLINATION
B. - Loosen large clamping nut, bring bracket to desired
B. - inclination, tighten the clamping nut firmly again.
B. - WIDTH
B. - By reconnecting the rubber jaws the distance of the
B. - bracket can be varied:
B. - a. 67 -87 mm - The lamellas of the rubber jaws are on
B. - a. 67 -87 mm - the outside
B. - b. 57 mm - The lamellas of the rubber jaws are inside
C. INSTRUMENT PLACEMENT
C. 1. At first place the instrument on the tray
C. 2. and afterwards lean against the bracket.
Remove rubber jaws
turn around
and put it back on again
a. b.
Foot circle ø 800 mm
