15010 Bassoon stand
- stable, robust and small foldable, therefore very suitable for mobile use
- extremely flexible retaining bracket
- very gentle on instruments (lateral rubber jaws; felt rear panel)
- width variably adjustable through reconnecting the rubber jaws
- height adjustable stepless from 700-1200 mm
- assembly and dismantling without tools
SAFETY INSTRUCTIONS
- Place the instrument carefully in the support tray and lean
- the body against the retaining bracket.
- Ensure that the surface is level and suitable
- The possibility of collapsing or adjusting the product hides
- risk of entrapment; therefore, careful and attentive handling
- during installation, operation, maintenance and dismantling
- is essential.
- The parquet protectors are made of high-quality material
- and are as far as possible free from plasticisers; for the
- protection of very sensitive floors (potentially regarding
- certain types of parquet) a non-slip underlay should be
- used when necessary.
INSTALLATION INSTRUCTIONS
The construction of the 15010 bassoon stands is very
simple. All parts are pre-assembled; the tripod only needs
to be positioned.
1. Remove stand and bracket from cardboard box
2. Loosen the clamping screw
3. Extend feet...
4. ...until strut connectors are horizontal
5. Tighten clamping screw firmly again
6. Loosen clamp on the clip,
6. Extend or retract telescopic tube,
6. retighten clamp
7. The assembly is carried out
7. in the reverse order
Thank you for choosing this product. This instruction manual informs you about the important steps to set up and handle the product. We recommend
to keep the manual in a separate place for a possible later use.
KÖNIG & MEYER GmbH & Co. KG
Kiesweg 2, 97877 Wertheim, www.k-m.de
15010-011-55 Rev.11 03-80-216-00 9/19
6.
3.
2.
5.
4.
