3
1) Scan the Enter Group 9-4 Label
2) Scan the User Define Label
3) Scan the Six Digit Labels in Table Hex (Page 49)
Tips:
• Refer to the Hexadecimal-Decimal Conversion Table (page 52) to acquire the 3 sets of barcode length
in Hexadecimal Number.
11dec => 0B hex
28dec => 1C hex
43dec => 2B hex
• Refer to the Table-Hex: HEXADECIMAL (page 49) and scan the 3 sets Labels accordingly. 0B 1C 2B
4) Scan the Confirm Label in Table-Hex: HEXADECIMAL (Page 49)
5) Go back to Group 9-4 and scan the “Exit” Label.
Setup Flow Chart
A. Enter group
B. Select items
C. Exit
Set all defaults Show version
Warning: All current settings will be lost and reset to the factory default.
Note: (*) denotes default setting. Options marked by ( ) are only available upon request.
To Next Page
