2
2.2 CH Dual Bass Audio System
This powerful and fashionable speaker set consist out of a so called 2.2
speaker system. Which means it is equipped with 2 satellite speakers
and a subwoofer with 2 bass drivers. The double bass output not only
offers a fast low frequency dynamic response but also delivers a very
strong sound in which every nuance in the lower frequency range is
crystal clear.
SPECIFICATIONS
AMP Output Power: 2x 17 W + 2x 8 W
Driver Output Power: 2x 30 W + 2x 10 W
Driver Unit: 2x 4” Subwoofer + 2x 3“ Sattelite
Frequency Response: 20 Hz – 20 KHz
S/N Ratio: 65 dB
Input Impedance: > 8 K Ohm
Sensitivity : 400 mV
Dimension Subwoofer: 260x200x260 mm
Dimension Satellite: 110x170x115 mm
FUNCTION
• Power ON/OFF
• Volume /Bass/Treble
