ASSEMBLY INSTRUCTIONS
1. Place the main body on the base, ensuring that holes in both com-ponents are correctly aligned,
then insert the screws and tighten.
2. Set the rear grille to the correct position on the motor shaft, with handle facing up.
3. Firmly tighten the mounting nut of the rear grille to secure it.
4. Install the blades on the shaft until the fixing pin is fully inserted into the blade notch.
5. Use 3 screws to install the decorative ring in the center of the front grille.
6. Mount the front safety grille on the rear grille by hanging it via the top hook. Close the latches
around the grille, then mount the nut and screw through the hole in the bottom edge of the front
grille, then tighten.
OSCILLATION FUNCTION
Start the fan swing by pressing the button (6) on the top of the motor housing and stop it by
moving the button upwards (6).
CLEANING
1. Disconnect the power cord from the power supply.
2. Carefully remove grilles and fan. Do not drop the fan.
3. Fan component parts should be cleaned with mild soap and a damp cloth or sponge. Do not
allow water or other liquids to enter the motor housing.
4. Carefully remove soap film with clear water.
