Delete the programmed stand-by power value:
• Switch connected devices to stand-by mode.
• Press the programming button „Prg.“ for
approximately 2 seconds.
• Here, the green LED changes from constant
illumination to blinking and indicates that
the saved value has been deleted and a new
programming procedure is necessary for the
function.
• The saved stand-by value is lost when the
power plug is pulled or there is a power
failure, indicated by the blinking, green LED.
This means it must be reprogrammed.
Technical data:
• 16A 250 V~ 50/60Hz
• Recognizable stand-by power range: 5 W -
100 W
• max. 3.600 W µ
• Power consumption: approx. 0.5 W
• IP 20
• (LxWxH) approx. 482.6 x 71 x 58.3 mm
• 19“ width
• Infrared sensor with sensor cable: approx.
1,5m
• Green LED status display
• Pushbuttons for the programming proce-
dure
