Dimensions
2. Dimensions
A
B
220222
C
120
2
-
4
0
120
140
2
-
3
3
Wiring connection port
204
94
Fresh air intake
Drain discharge port
Refrigerant pipe hole
Hanging arm
D
Capacity (Btu/h)
A B C D
36K 1285 675 235 1200
48K 1650 675 235 1565
