Korg DTR-1000 Service Manual

PART CODE PART NAME NOTE Q’TY
001235600
PCB ASSY KLM-2356/57 DTR-2000 M.PART 1
001235800
PCB ASSY KLM-2358 DTR-2000 M.PART 1
304050140
DIGITAL TR DTC114EKA T146(TS) KLM-2356/57 DT 2
304050140
DIGITAL TR DTC114EKA T146(TS) KLM-2358 DTR-2 40
304050150
DIGITAL TR DTA114EKA T146 (TS) KLM-2358 DTR-2 5
304060070
FET 2SK433-T12-1C (TS) KLM-2356/57 DT 1
310011700
DIODE BRIDGE DBF10C KLM-2356/57 DT 1
314001800
DIODE 1SS355 TE-17 (TS) KLM-2356/57 DT 6
314001800
DIODE 1SS355 TE-17 (TS) KLM-2358 DTR-2 2
320009062
IC NJM-78M05FA KLM-2356/57 DT 1
320011216
IC M38034M4-297HP KLM-2358 DTR-2 1
324011002
IC M5223FP-600C (TS) KLM-2356/57 DT 1
324011016
IC M51951AML-600C (TS) KLM-2358 DTR-2 1
335010600
CRYSTAL OSC HC-49US 8.00MHZ KLM-2358 DTR-2 1
454004300
PHONE JACK YKB21-5012 KLM-2356/57 DT 6
454007900
PHONE JACK YKB21-5176 (GOLD) KLM-2356/57 DT 2
471050201
CONNECTOR TOP B2P3-VH KLM-2356/57 DT 1
471070200
CONNECTOR TOP B2B-PH-K-S KLM-2358 DTR-2 1
471070300
CONNECTOR TOP B3B-PH-K-S KLM-2356/57 DT 2
471070400
CONNECTOR TOP B4B-PH-K-S KLM-2356/57 DT 2
471070600
CONNECTOR TOP B6B-PH-K-S KLM-2358 DTR-2 1
471070600
CONNECTOR TOP B6B-PH-K-S KLM-2356/57 DT 1
471070900
CONNECTOR TOP B9B-PH-K-S KLM-2356/57 DT 1
472070900
CONNECTOR SIDE S9B-PH-K-S KLM-2358 DTR-2 1
474022200
PIN HEADER B4P-LV-TN KLM-2356/57 DT 1
540020200
INLET SOCKET SS-7B M.PART 1
600003300
CORD UC-953-J01 M.PART 117CN 1
600003300
CORD UC-953-J01 M.PART 117US 1
600004700
CORD EC-652-E03 M.PART 230GE 1
600005300
CORD DC-480-J01 M.PART 100JP 1
600005800
CORD SC-111-J01 M.PART 240AU 1
*315X161H02
LED NSCW100 (WHITE) KLM-2358 DTR-2 1
*315X161H03
LED 42-21SURC/S530-A2/TR8(RED) KLM-2358 DTR-2 4
*315X161H04
LED ELS-826HWB DIGIT (RED) KLM-2358 DTR-2 1
*315X161H05
LED 15-21 SRC/TR8(HT) (RED) KLM-2358 DTR-2 76
*315X161H06
LED 15-21UBC/C470 (BLUE) KLM-2358 DTR-2 2
*375X161H00
PSW KDC-A04-10(B)B1-G KLM-2356/57 DT 1
*400X161H00
POWER TRANSFORMER TA-083 M.PART 117CN 1
*400X161H00
POWER TRANSFORMER TA-083 M.PART 117US 1
*400X161H00
POWER TRANSFORMER TA-083 M.PART 100JP 1
*400X161H01
POWER TRANSFORMER TB-083 M.PART 240AU 1
*400X161H01
POWER TRANSFORMER TB-083 M.PART 230GE 1
*400X161H01
POWER TRANSFORMER TB-083 M.PART 230UK 1
*403X161H00
RELAY EA2-9 NU KLM-2356/57 DT 2
*410X161H00
CONDENCER MIC KUC2423 KLM-2358 DTR-2 1
*464X161H00
FUSE T125MA/250V M.PART 117US 1
*464X161H00
FUSE T125MA/250V M.PART 117CN 1
