Koyker 545 - ATTACHING THE BUCKET

ATTACHING THE BUCKET
Page 9
1. For Fast Attach Buckets, first tilt the bucket adapter forward so the top round pipe slides into the
receiver on the bucket (Fig. 9-1). Rotate the bucket back so the two rear pins line up with the holes
on the base plates of the bucket (Fig. 9-2). Turn both pins on bucket adapter so they drop through
the holes in the base plate of the bucket (Fig. 9-3). Put #6 hitch pin in place (Fig 9-4).
Fig. 9-1 Fig. 9-2
Fig. 9-3 Fig. 9-4
