Step 4:
Step 5:
Connect Main Beam 1 and Main Beam 2 to the four Poles using Bolt M.
1. Insert Hook Part N into the slot of Part D.
Note: Keep Hook P and C1/C2/C
on the same side of Part E.
2. Insert Hook P and Hook O into the slot of Part E.
• Please ensure that Hook P is inserted according
to the method shown in the diagram and not the
opposite way.
