Cable tracker
7
ENG
2) Use the sender (switch to “TONE”): Connect the test leads to the subject
pair, using the receiver touch the wire end with clip lead, reception of tone is
an indication of continuity.
*ATTENTION: DO NOT CONNECT TO ANY ACTIVE AC OR DC CIRCUIT IN
THIS MODE.
Send tone:
Connect the test leads to the pair, or attach one lead to ground and one
lead to either side of the line. A dual alternating tone, or a single solid tone
can be selected from the switch inside the sender. Probe the suspected
wires with the receiver, reception of tone will be strongest on the subject
wire. In case of ready access to bare conductors, the receiver may be
used to receive the tone.
*ATTENTION: DO NOT CONNECT TO ANY ACTIVE AC CIRCUIT EXCEED-
ING 24V IN THIS MODE.
Track cables or wires:
Use sender (switch to “TONE”) and Receiver. Connect the test leads to the
pair, or attach one lead to ground and one lead to either side of the line,
using the receiver close to and along the object pair, and reception of the
tone is indication tracking.
*ATTENTION: DO NOT CONNECT TO ANY ACTIVE CIRCUIT IN THIS MODE.
Identify the state of working telephone line:
Use sender (switch “OFF”)
1) Identify TIP & RING. Connect the red test lead to the side of one line and
the black lead to the another side of line.
• “CONT” indicator light is green when you connect the red test lead to the
ring side of line.
• “CONT” indicator light is red when you connect the red test lead to the
TIP side of line.
2) Identify CLEAR, RINGING, BUSY state on the working telepohne line:
Connect the red test lead to the RING side, black to the TIP side.
• “CONT” indicator light is green, indicater a clear line.
• “CONT” indicator dose not glow, indicates a busy line.
• “CONT” indicator light brightly flickering yellow, indicates a ringing time.
(Switching to “CONT” will terminate the call on the subject line)
3) In cases of ready access to bare conductors, receiver may be used to
receive the tone.
