Kraft Powercon PRX Series User Manual

8
KraftPowercon Sweden AB, Hjalmar Petris väg 49, 352 46 Växjö, Sweden, Tel: 0470-705200, Fax: 0470-705201,
www.kraftpowercon.com
3.1.4 Electrical data for rectifier module
Model
designation,
rectifier
module
Output data
Input data
Power
loss
*2
UNOM
Setting
range
IRATED
Voltage
range
*3
Mains
power
*1
Mains
current
*1
(VDC)
(VDC)
(A)
(VAC)
(VA)
(Arms)
PCS 24/36
24
22 – 33
36
90 - 290
1150
6
150
PCS 24/70
70
90 - 290
2200
12
175
PCS 48/18
48
42 – 63
18
90 - 290
1150
6
135
PCS 48/50
50
90 – 290
2900
15
210
PCS 110/8
110
100 – 158
8
90 – 290
1150
6
135
PCS 110/16
16
90 – 290
2200
12
160
PCS 110/22
22
90 – 290
2900
15
200
PCS 220/10
220
187 – 292
10
90 - 290
2700
14
200
*1
: max at 195 VAC
*2
: type at 230 VAC and full load
*3
: Power derating below 190 VAC.
3.2 Environmental data
Class of enclosure ...................................................... IP21 as per EN 60529
Cooling........................................................................ Temperature controlled fans in rectifier
modules
Ambient temperature (specified data applies) ...... 0 to +40 °C
Storage temperature .................................................. -40 to +70 °C
Humidity .................................................................... <90 % RH, non-condensed
Altitude above sea ..................................................... <2000 m
Noise level at 1 m, +20 °C, 25 % load ..................... <50 dBA
3.3 Mechanical data
Design ......................................Wall cabinet
Arrangement ...........................On a wall indoors in dry, clean room
Weight ......................................18 kg, fully equipped
Dimensions..............................400/274/333 mm (h/w/d), see also dimension diagram Appendix_A
Colour ......................................RAL 7035 light grey
Cable inlets ..............................From underneath
3.4 Conformity with standards
EN 60529 .............................. Class of enclosure IP21
EN 50178 .............................. LVD. Electronic equipment, including power electronics in electrical
power installations.
EN 50272-2........................... Safety requirements for secondary batteries and battery installations
EN 61000-6-2 ....................... EMC. Immunity for industrial electronics
EN 61000-6-4 ....................... EMC. Emission from industrial electronics
