Kramer Tavor 5-O User Manual

Tavor 5-O - Defining the Tavor 5-O
7
7
#
Feature
Function
1
SPEAKER OUT Connectors
Connect the active speaker to the (+) and (-)
stereo sockets on the passive speaker
The L speaker is active and the R speaker is
passive
2
INPUT
Connectors
5-pin Terminal Block
Connect the audio source to one or more of the
input connectors
3
3.5mm Mini Jack
4
L and R RCA
5
BASS Control Knob
Rotate the button to control the bass
6
TREBLE Control Knob
Rotate the button to control the treble
7
VOLUME Control knob
Rotate the button to adjust the audio volume
8
AC-Input Power Supply (self
adjusting)
Connect to the AC power cord
9
POWER Switch
For turning the unit ON (I), OFF (0) or AUTO
shutoff (II)
When selecting the AUTO shutoff mode, the
speaker enters the standby mode when idle
for over 10 minutes
10
POWER/STANDBY LED
Illuminates in green when powered (POWER
switch set to ON or AUTO)
illuminates in red when in the standby mode
(POWER switch is set to AUTO)
In the AUTO mode, the LED illuminates green
if an input signal is detected and illuminates
red if idle for over 10 minutes
11
LOOP OUTPUT 3.5mm Mini Jack
Connector
Connect to another pair of active speakers
12
SUB OUT 3.5mm Mini Connector
If required, connect an active sub-woofer to this
output for maximum bass reproduction
