Tavor 6-O - Technical Specifications
6 Technical Specifications
Audio and Power
DESCRIPTION:
2-way powered speaker
BUILT IN POWER AMPLIFIER:
2 X 50W RMS
2 X 140W continuous program
FREQUENCY RESPONSE:
45Hz to 20kHz @ -10dB
50Hz to 20kHz @ -3dB
WOOFER:
6 1/2” polypropylene cone with rubber edge woofer
TWEETER
1” Silk dome tweeter
SENSITIVITY:
85dB SPL, 1W@1m
MAX SPL:
Continuous: 100dB
Peak:108dB
POWER SOURCE:
90−240V AC 50/60Hz
IMPEDANCE
4Ω
CROSSOVER FREQUENCY:
8kHz
DIRECTIVITY FACTOR (Q):
7.5 averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI):
8.7dB averaged 1kHz to 10kHz
INPUT CONNECTORS:
Line level unbalanced stereo audio on a 3.5mm mini jack
Line level balanced stereo audio on a terminal block
connector
Line level unbalanced stereo audio on left and right RCA
connectors
OUTPUT CONNECTORS:
Speaker (to connect to the external passive speaker)
3.5mm mini jack lineout for optional sub-woofer
3.5mm mini jack Loop output
DISPERSION COVERAGE:
Vertical: 54 degrees @2000Hz
Horizontal: 65 degrees @2000Hz
DAMPING FACTOR:
19 @ 4Ω/1000Hz
S/N RATIO:
80-90dB
THD:
≦0.15%
CONTROLS:
Volume, bass and treble
INPUT POWER:
ON or AUTO
STANDBY MODE POWER CONSUMPTION:
0.5W
INPUT LEVEL FOR SYSTEM “WAKE-UP”
FROM STANDBY MODE:
12mV
