Kramer TP-583Txr Quick Start Guide

Technical Specifications
TP-583T
Input
1 HDMI
On a female HDMI connector
Output
HDBT
On an RJ-45 connector
Port
RS-232
On a 3-pin terminal block connector for serial link extension
IR
On a 3.5mm mini jack connector
TP-583R
Input
HDBT
On an RJ-45 connector
Output
1 HDMI
On a female HDMI connector
Port
RS-232
On a 3-pin terminal block connector for serial link extension
IR
On a 3.5mm mini jack connector
General
Video
Transmitted Data Bandwidth
Up to 18Gbps (6Gbps per graphic channel)
Max Resolution
Standard compression level
4096x2160@60Hz (4:4:4) 24bpp
High compression level
3840x2160@60Hz (4:4:4) 24bpp
Compliance
HDMI 2.0, HDCP 2.2, HDR 10
Reach Extension
We recommend that you use Kramer shielded cables to achieve optimum extension ranges.
Standard Compression Level
Up to 40m (130ft) at 4K@60Hz (4:4:4)
Up to 70m (230ft) at 4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
High Compression Level
Up to 70m (230ft) at 4K@60Hz (4:4:4), 4K@60Hz (4:2:0) and full HD
(1080p @60Hz 36bpp)
Extended RS-232
Baud Rate
300 to 115200
Controls
Front Panel
IN, OUT, LINK and ON LED indicators
Rear Panel
DIP-switches
Power
Consumption
12V DC, TP-583T 480mA; TP-583R 680mA
Source
12V DC, 2A
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory Compliance
Safety
CE, UL
Environmental
RoHs, WEEE
Enclosure
Size
Tool
Type
Aluminum
Cooling
Convection ventilation
General
Net Dimensions (W, D, H), each
12cm x 7.2cm x 2.4cm
(4.7" x 2.8" x 0.94")
Shipping Dimensions (W, D, H)
15.7cm x 12cm x 8.7cm
(6.2" x 4.7" x 3.4")
Net Weight, each
0.2kg (0.44bs) approx.
Shipping Weight
0.72kg (1.6lbs) approx.
Accessories
Included
1 Power adapter, 1 power cord and 1bracket set per device
