Kramer TP-590TXR Quick Start Guide

Step 5: Connect the power
Connect the 48V DC power supply to TP-590TXR and plug it into the mains electricity.
Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning:
Use only the Kramer Electronics power supply that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com for updated safety information.
Step 6: Operate TP-590TXR
Operate TP-590TXR via:
• Remotely, using Protocol 3000
commands via RS-232 or
Ethernet
• Embedded web pages via the
Ethernet
• Remotely, using an IR remote
control transmitter
Default Parameters
Parameter
Value
Name
KRAMER_
Model
TP-590TXR
IP Address
192.168.1.39
UDP Port
50000
TCP Port
5000
Network Mask
255.255.0.0
Gateway Address
192.168.0.1
RS-232 Baud Rate
115200
Audio delay input switching on new signal
0 seconds
Audio delay input switching on signal loss (leave 5V on)
5 seconds
Audio delay input switching on cable unplug
0 seconds
Video delay power off 5V on signal loss
15 minutes
HDCP Mode
Follow output
Protocol 3000 Commands
Command
Description
Command
Description
#
Protocol handshaking
LOCK-EDID?
Get EDID lock state
AUD-EMB?
Get audio in video embedding status
LOGIN
Set/get protocol permission
AUD-SIGNAL?
Get audio input signal status
LOGOUT
Cancel current permission level
AV-SW-MODE?
Get auto switch mode
MODEL?
Read device model
AV-SW-TIMEOUT
Set/get video auto-switch timeout
NAME
Set/get machine (DNS) name
BUILD-DATE?
Read device build date
NAME-RST
Reset machine name to factory default
(DNS)
CPEDID
Copy EDID data from the output to the input
NET-DHCP
Set/get DHCP mode
DIR
List files in device
NET-GATE
Set/get gateway IP
DISPLAY?
Valid / Invalid output
NET-IP
Set/get IP address
ETH-PORT
Set/get Ethernet port protocol
NET-MAC?
Get MAC address
FACTORY
Resets the device to factory default
NET-MASK
Set/get subnet mask
FS-FREE?
Get file system free space
PASS
Set/get Password
GEDID
Read EDID data
PRIORITY?
Get priority for all channels
GET
Get file
PROT-VER?
Get device protocol version
HDCP-MOD
Set/get HDCP mode
RESET
Reset device
HDCP-STAT?
Get HDCP signal status
SECUR
Start / Stop Security
HELP
Get command list or help for specific
command
SIGNAL?
Get input signal lock status
LDEDID
Write EDID data to input
SN?
Read device serial number
LDFW
Load new firmware
UPGRADE
Perform firmware upgrade
LOAD
Load new firmware
VERSION?
Read device firmware version
