Technical Specifications
11
11
7 Technical Specifications
The VM-73 technical specifications are shown in Table 2:
Table 2: VM-73 Technical Specifications
1
Composite Y/C Component XGA HDMI
INPUTS: 1 composite
on a BNC
connector
1 s-Video
on a 4-pin
connector
1 component
(Y, Pb/Cb, Pr/Cr)
on 3 RCA
connectors
1 XGA on a
15-pin HD
connector
1 HDMI on
an HDMI
connector
OUTPUTS: 3 composite
on BNC
connectors
3 s-Video
on 4-pin
connectors
3 component
(Y, Pb/Cb, Pr/Cr)
on 3 RCA
connectors each
3 XGA on
15-pin HD
connectors
3 HDMI on
HDMI
connectors
OUTPUT LEVEL: 1.8Vpp 1.9Vpp 2.0Vpp 2.0Vpp
BANDWIDTH (-3dB): 430MHz 440MHz 430MHz 405MHz 2.25Gbps
DIFF. GAIN: 0.05% 0.06% 0.05% 0.05%
DIFF. PHASE: 0.05Deg 0.02Deg 0.05Deg 0.03Deg
S/N RATIO @5MHz: 62dB 62dB 74dB 69dB
COUPLING: DC Y-DC, C-AC DC DC
K-FACTOR: <0.05%
CROSSTALK (all hostile): -60dB
POWER SOURCE: 100-240V AC, 100mA
DIMENSIONS 19 " x 7" x 1U W, D, H
WEIGHT: 2kg (4.4lbs)
ACCESSORIES: Power cord, rack “ears”
1 Specifications are subject to change without notice
