Technical Specifications
8
Table 3 defines the OSD Menu and parameters.
Table 3: The OSD Settings Menu and Parameters
Parameter Function Value Range Factory Default
H POSITION Adjusts the OSD horizontal
position
From 0 to 42 007
V POSITION Adjusts the OSD vertical position From 0 to 24 005
TIMEOUT Adjusts the OSD menu timeout Off/From 3 to 30 005
TRANSPARENCY Adjusts the OSD transparency From -0 to 15 010
EXIT Exits the OSD Settings menu to
the Display Menu (see
Table 2)
7 Technical Specifications
Table 4: Technical Specifications
1
INPUTS:
of the VP-410 Video-Audio to HDMI Scaler
1 composite video (1Vpp/75 Ω) on an RCA connector
1 unbalanced audio (1Vpp/47kΩ) stereo on RCA connectors
OUTPUT: 1 HDMI
OUTPUT RESOLUTIONS
2
HDTV: 480p, 576p, 720p, 1080i, 1080p :
PROCESSING DELAY: 2 frames
CONTROLS: Front panel buttons for output resolution and menu driven OSD control
ADDITIONAL CONTROLS: Contra
st, brightness, saturation, hue, auto sync, aspect ratio, over scanning,
noise reduction
POWER SOURCE: +5V DC, 430mA
DIMENSIONS: 12cm x 6.9cm x 2.4cm (4.72” x 2.72” x 0.94”) W, D, H
WEIGHT: 0.4kg (0.88lbs) approx.
ACCESSORIES: Power supply
OPTIONS: 19" rack adapter RK-3T
1 Specifications are subject to change without notice
2 All resolutions are outputted @ 60Hz, except 576p which is outputted @ 50Hz
