03/2016Universal electronic driver type KRED for solenoid operated proportional valves
6
7 ADjUSTMENT KRED
0% 3% 5% 25%
1,00
2,00
3,00
0,00
100 Hz 200 Hz
0 50 100
0.00
1.00
2.00
3.00
0
0.00
1.00
2.00
3.00
150 0
500
0
0 V
4 mA
3.00
2.00
1.00
5 or 10 V
20 mA
3.00
0.00
0 V
4 mA
2.00
1.00
5 or 10 V
20 mA
3.00
0.00
5 10
Adjustment of Maximum:
(High) / parameter „Hi“
Maximum Current output 0,20 - 3,00 A
Time[s]
Time [s]
Command signal [V or mA]
Solenoid current [A]
Adjustment Ramp
(Ramp up) / parameter „rUP“
Time for Output to Increase from min to max 0 - 99,5 s
Adjustment Ramp
(Ramp down) / parameter „rdn“
Time for Output to Decrease from max to min 0 - 99,5 s
Adjustment (Command deadband) /parameter „Cdb“
Output disabled if command signal less than deadband
0 - 5 % of the maximum Command signal
DITHER FREQUENCY / parameter „dFr “
Frequency settable in a range of 40 - 450 Hz
Command signal [V or mA]
Time [ms]
Command signal [V or mA]
Solenoid current [A]
Solenoid current [A] Solenoid current [A]
Solenoid current [A]
Solenoid current [A]
Adjustment of minimum
(Low) / parameter „Lo“
Maximum Current output 0,00 - 2,99 A
