Kranzle 2+2 - Roller Replacement

7
Servicing
Whentherollersareworn,thesweepercan
beplacedapprox.1-1,5mmlowerbyremo-
vingthetwowashersno.13(seepage10).
Important:

Easyreplacementofbrushrollers:
1)Putthemachineuprightonthejointsof
thefolded-inpushbarandtheframe.
2)Turnthebrushrolleruntilthetwoscrews
no.34ontheleftandrightsiderespectively
arevisible(seepage12)andremovethese
4screws.
3)Turnthebrushrollersanotherhalf-turn
andremovethembypullingthemout.
4)Fitthenewrollersinthereverseorder.
One washer no. 13  must
always be kept under the
screwholetoavoiddamaging
totheplasticframe
