Kratki SIMPLE BOX - Page 15

15
EN
Step 8: Mount the frame of the upper part of the superstructure as shown in the diagram below.
The diagram also shows that the side and front panels should extend 2 mm beyond the ange of the
replace frame.
2
2
Śruba M5x10
Screw m5x10
