17
EN
Step 10: Insert the side panel by inserting it into the notches in the substructure, using the hooks that
must be fastened after inserting it according to the diagram below. Before installation, screw the hooks
as shown in the diagram below and screw the hook screws to the top of the side panel by only partially
screwing it in (a few coils of thread) to leave room for the hook of the top panel.
B
B
ZACZEP
Śruba M5x10
Hook
Screw M5x10
