19
EN
Step 12: Prepare the smaller front panel before installing it on the building structure, as shown in the
diagram below. Depending on the BSL or BSP version, screw in the appropriate hangers according to
the schemes below.
Panel mniejszy z wieszakami w wersji BSL
Panel mniejszy z wieszakami w wersji BSP
Wieszak do kominka
z przeszkleniem
po lewej stronie
Śruba M4x6
Wieszak do kominka
z przeszkleniem
po prawej stronie
Śruba M4x6
Smaller panel with hangers
in BSL design
Smaller panel with hangers
according to GNP
Schraube m4x6
Screw m4x6
Fireplace hanger with
glazing on the left side
Fireplace hanger with
glazing on the right
sidee
