Step 4: Install drain
1. Remove waste stopper (16) from drain (17). Remove drain body (22),
mounting nut (21), plastic washer (20), and concave washer (19) from
drain (17)
2. Insert lift pole rod (13) through the hole in the back of the faucet body
(6). Attach lift pole extension (15) to lift pole rod (13) by using connector
(14). Secure tightly
3. Install drain (17), with rubber washer (18) attached, into the drain hole
From underneath countertop, attach concave washer (19), plastic
washer (20), and mounting nut (21) to drain (17), and secure tightly to
sink. Thread drain body (22) onto drain (17). Hand-tighten
4. Insert waste stopper (16) into drain (17). Make sure hole in brass screw
on waste stopper (16) is aligned with drain body (22) opening
5. Remove retaining nut (27) from drain body (22). Leave top hat washer
(25) inside drain body (22)
6. Insert shortest end of drain-o pole (23) into drain body (22). Attach
washer (26) and retaining nut (27) through drain-o pole (23). Secure
retaining nut (27) to drain body (22)
7. Align drain body (22) to enable drain-o pole (23) and lift pole extension
(15) to engage
8. Connect lift pole extension (15) and drain-o pole (23) using elbow
connector (24). Adjust and tighten elbow connector (22) with Phillips
head screwdriver
