Kraus KPF-1680CH - Step 1: Remove mounting hardware; Step 2 A: Faucet installation - with deck plate

Step 1: Remove mounting hardware
Remove the mounting
screws (4C), mounting nut
(4B), and rubber & metal
washer (4A) from the
mounting pipe
Step 2A: Faucet installation - with deck plate
For three-hole installation:
Deck plate (3A), base plate
(3B), and silicone sealant
(optional) are required
