Kraus Merlin KPF1674SFS - Page 5

55
Installer Tip:
Shut off main water supply before installing new faucet.
Faucet Installation Procedure
MAX.
1 3/8"
(35mm)
Ø1 3/8"
(35mm)
11 1/4"
(284.7mm)
8 5/8"
(218.5mm)
12°
9 1/8"
(231.5mm)
5 7/8"
(149.8mm)
6 7/8"
(175mm)
3 3/4"
(94.6mm)
1 1/8"
(30mm)
15 5/8"
(396.4mm)
