Diagram and Parts List
1. Spray Head
2. Faucet Body
3. Hot and Cold Waterlines
A. Hot
B. Cold
4. Quick Connector
5. Mounting Hardware
A. Rubber Washer
B. Metal Washer
C. Mounting Nut
D. Mounting Screws
6. Spray hose
7. Weight
8. Hex Wrench
9. 2.2 GPM Flow Restrictor
(BLACK)
10. Base O-Ring
Adjustable Wrench
Silicone Sealant
(optional)
Phillips Screwdriver
Safety Goggles
1
3A
3B
4
5A
5C
5D
2
6
7
8
Tools you will need
9
5B
10
